Digital Motor Checker EMC-38N
Digital Motor Checker EMC-38N Digital Motor Checker EMC-38N Digital Motor Checker EMC-38N Digital Motor Checker EMC-38N

Digital Motor Checker EMC-38N

Product Details:

  • Product Type Digital Motor Checker EMC-38N
  • Color White
  • Dimension (L*W*H) 237x131x45 Millimeter (mm)
  • Weight 700 Grams (g)
  • Click to View more
X

Digital Motor Checker EMC-38N Price And Quantity

  • 10 Piece

Digital Motor Checker EMC-38N Product Specifications

  • 700 Grams (g)
  • Digital Motor Checker EMC-38N
  • White
  • 237x131x45 Millimeter (mm)

Product Description

DIGITAL MOTOR CHECKER EMC-38N

MCM Introduces new feature in Motor Checker Detects machinery noise in industrial Environments

Test all kinds of Motors and Coil based Devices

Electric Motor, Generator and Transformer

Trouble Shooter

Know in a few minutes what the problem is: Electrical or Mechanical?

Complete Condition of STATOR, ROTOR, Coil, Connections, Internal Fault or Ground Fault? & detect Mechanical

Noise of Machines / Bearing, gear and pump noise.

Features:

  • Insulation Resistance (IR) Measurement
  • Detects blow holes or cracks in the Rotor bar
  • without dismantling the rotor
  • Inductance Measurement of the winding
  • Low resistance measurement of the winding
  • Identifies open and short circuits / loose
  • Connections in a winding coil
  • Identifies intertern shorts
  • Simple operation accurate & quick assessment of
  • motor condition.
  • Noise (Mechanical sounds detection)
  • For easy location of machinery noise in
  • industrial Environments
  • Very handy
  • Battery Condition of Instrument
  • Low battery Indication
  • Light Weight


PREDICTIVE MAINTENANCE:

Regular testing can identify developing faults before a failure occurs. All measurement data can be trended for predictive maintenance condition monitoring. By making proactive repairs and eliminating unscheduled down- time, plant productivity is greatly improved. EMC-38N is a Digital portable diagnostic tool for Electrical Engineer and is used for quick on - site checks of electric motor and other three - phase machines.

A reduction in machine performance, such as inefficient operation or tripping of overloads, may indicate mechanical or electrical faults. If the fault is electrical the EMC-38N will immediately detects it, without dismantling the equipment. The instrument has three separate operating modes to measure different types of faults like fully insulation, open circuits / loose connections, short circuits, Ground faults and rotor defects. Motor insulation is tested with a high voltage at 500V/1000VDC supplied by the instrument.

NOISE:(Electronic stethoscope)Listening to machine sounds in order to determine the probable source of abnormal noise is one of the most widely used methods in maintenance departments across all branches of industry. Our electronic stethoscope is a practical and easy-to-use listening device that helps pinpoint the source of mechanical noise in a broad range of applications. Bearing condition, gear and pump noise, and electric relay operation are just a few of the many sounds which can be identified, amplified, and assessed.

Motor Checker EMC-38N finds the faults you can't see with any other hand held instrument

  • Turn -to-turn , coil-to-coil and phase-to-phase faults
  • Open phase
  • Burned or contaminated winding
  • Poor Connections
  • Broken / Cracked rotor bars
  • Grounded windings
  • Cable faults.
  • Mechanical Noise of Machines / Bearing, gear and pump noise


Technical Specification :

A) INSULATION RESISTANCE:

0 - 200 M at 500 V DC( 2% + 1 digit), 0.1 M resolution

B) RESISTANCE

RANGE

(OHMS) F.S.R

RESOLUTION

1

200

0.10 Ohms

2

20

0.01 Ohms

3

2

0.001 Ohms

4

0.2 (200m Ohms)

0.10 milli Ohms

C Noise (Stethoscope

Frequency range: 30 Hz to 20 kHz


Filters: low, middle, high, unfiltered

C) INDUCTANCE

RANGE

(mH) F.S.R

RESOLUTION

1

2000

1 mH

2

200

0.1 mH

20

0.01 mH

4

2

0.001 mH

  • Display: 1/2 LCD
  • Temp. Operating Range: 0- 55 C
  • Size: 237x131x45
  • Weight: 700gms
  • Power: 1.5V x 6 AA size cells
  • Enclosure: Moulded in high impact ABS

Standard Supply :

  • Motor Checker EMC-38N
  • Test Leads - 1 set
  • Noise Probe with Tip
  • Head Phone
  • Batteries - 6nos
  • Manual
  • Calibration Report & Warranty / Guarantee Certificate
  • Carry Case
