Portable Vibration Monitoring VIB-30 PLUS
Portable Vibration Monitoring VIB-30 PLUS
Product Code : MCM-01
Brand Name : MCM INSTRUMENTS
Vibration Meter VIB-30Plus
- Vibration Meter VIB-30Plus is Micro controller based and has been designed as simple diagnostic tool for preventive maintenance. The instrument and the monitoring techniques are based on the recommendations of ISO standard.
- Need based maintenance is the latest trend of industry with which maintenance costs are low and life machinery is most optimum. Condition monitoring is basic need for maintenance.
- The above useful measurement is possible with VIB-30Plus. Velocity mode allows a user to perform basic vibration analysis.
Features
- Measuring Vibration Velocity
- True RMS measurement
- Sealed Membrane key pad
- Micro Controller based
- Black Light Display
- Auto Off
- Battery Low Indication with text
- Pocket Size & Light Weight
Technical Data
- Velocity Measuring Range: 0.1 - 200 mm/s True RMS & PEAK
- Resolution: 0.1mm/s
- Accuracy: ñ (2% + 0.1mm/s)
- Frequency response : 10HZ - 1KHZ
- Temperature Range 0-55 degree C
- Power Supply: 9V - 6 F22
- Display: 2 x 8 Dot Matrix LCD Large Characters with back light
- Casing ABS
- Auto Off: Yes
- Battery Low Indication: Yes
- Weight: 200 gms
Standard Supply:
1) Vibration Meter VIB-30 with Protective Pouch,
2) Vibration Transducer (Accelerometer)VSF-1F, Magnetic Base, Hand Held Probe Rod, Low Noise Cable with Connectors (1.5 Mtrs),
3) 9V Battery (Alkaline)
4) Test & Calibration Report with Warranty/ Guarantee Certificate
5) Manual
6) Carry Case.
|
